5.4: Fuse Box
The diagram below shows the layout of the fuse box & the rating for each
fuse.
Relay Loom Fuse Table
Fuse Amps Function
1-Diesel 7.5
Mast Height Override, Dash Display Lights, Glow Plug Light, Glow Plug Relay, Alternator
1 – LPG 7.5 Mast Height Override, Dash Display Lights, Alternator Plug
2 7.5
Forward/Reverse Supply, Joystick Supply, Neutral Relay, Reverse Bleeper
3 – Diesel 7.5 Pull Hold Solenoid, Fuel Pump
3 – LPG 7.5 Ignition Coil, Fuel Commander
4 20 Steering Solenoid Supply
5 7.5
Push Button Brake Switch, Inch Pedal Brake Switch, Brake Light, Brake Solenoid Supply
6 10 Wipers
7 15 Front Work Lights
8 15 Side Work Lights, Optional Cabin Interior Light
9 7.5 Cabin Heater Fan, Cabin Cooling Fan, Optional Radio
10 7.5 Horn
11 7.5 Optional Extra Solenoid (e.g. Independent Fork Positioner)
12 7.5 4-Way Switching Supply
13 7.5 Flashing Beacon
14 7.5 Optional Road Lights
PLC Loom Fuse Table
Fuse Amps Function
1-Diesel 7.5
Mast Height Override, Dash Display Lights, Glow Plug Light, Glow Plug Relay, PLC Supply
1 – LPG 7.5 Mast Height Override, Dash Display Lights, PLC Supply
2 7.5 Joystick Supply, Neutral Relay, Reverse Bleeper
3 – Diesel 7.5 Pull Hold Solenoid, Fuel Pump
3 – LPG 7.5 Ignition Coil, Fuel Commander
4 20 Steering Solenoid Supply, PLC Output Supply
5 7.5
Push Button Brake Switch, Inch Pedal Brake Switch, Brake Light, Brake Solenoid Supply
6 10 Wipers
7 15 Front Work Lights
8 15 Side Work Lights, Cabin Interior Light
9 7.5 Cabin Heater Fan, Cabin Cooling Fan, Optional Radio
10 7.5 Horn
11 7.5 Proximity Switch Supply, Guide Roller Light
12 7.5 Spare
13 7.5 Flashing Beacon
14 7.5 Spare
