5.6: Dash Relay Layout (PLC Loom)
Below is a diagram of the layout of the relays inside the dash in the cabin of
the Combilift truck with a PLC loom.
Relay Function
1 Starter
1a Glow Plug Timer
9 Steering Solenoid Supply
15 Neutral Cut-Off
22 Work Lights (Spot Lights)
1a
