Combilift Ltd. C4000-C5000XL O&S Manual
5-24
C4000-OM-EN-08
5.15: Colour Codes for Electric Circuits:
CODE - COLOUR
NEGATIVE WIRES ARE NORMALLY BLUE
OR BLACK, DEPENDING ON WHAT UNIT
IS BEING INVESTIGATED.
TAKE ALL NEGATIVES TO BE BLACK
UNLESS STATED OTHERWISE.
BK - BLACK
BN - BROWN
BL - BLUE
R - RED
O - ORANGE
Y - YELLOW
GR - GREEN
V - VIOLET
P - PINK
GY - GREY
W - WHITE
G/Y - GREEN / YELLOW
R/Y - RED / YELLOW
O/W - ORANGE / WHITE
