Combilift Ltd. C4000-C5000XL O&S Manual
iii
C4000-OM-EN-08
Section 5: Technical Information & Circuit Diagrams ............................. 5-1
5.1: Towing the Combilift ................................................................................. 5-1
5.2: Mechanical Brake Release ......................................................................... 5-2
5.3: Checking The Charge Pressure .................................................................. 5-3
5.4: Fuse Box .................................................................................................... 5-4
5.5: Dash Relay Layout (Relay Loom) ............................................................. 5-5
5.6: Dash Relay Layout (PLC Loom) ............................................................... 5-6
5.7: Steering & Hydraulic Functions Circuit .................................................... 5-7
5.8: Hydraulic Drive Circuit: ............................................................................ 5-8
5.9: Standard Diesel Electric Circuit: ............................................................... 5-9
5.10: Standard LPG Electric Circuit: ................................................................ 5-12
5.11: Tier IV LPG Electric Circuit: .................................................................. 5-15
5.12: Diesel Electric Circuit (PLC): .................................................................. 5-18
5.13: LPG Electric Circuit (PLC): .................................................................... 5-20
5.14: Tier IV LPG Electric Circuit (PLC) ......................................................... 5-22
5.15: Colour Codes for Electric Circuits: .......................................................... 5-24
5.16: PLC Details .............................................................................................. 5-25
5.17: PLC Diagnostics ...................................................................................... 5-28
