Combilift Ltd. C4000-C5000XL O&S Manual
5-27
C4000-OM-EN-08
Outputs (continued)
Plug Pin Function WireColour
X5.1 01 NotUsed n/a
X5.1 02 CommonSupplyforOutput08(Fromfuse4) Brown
X5.1 03 SteeringSolenoid(SixPort) Brown
X5.1 04 NotUsed n/a
X5.1 05 NotUsed n/a
X5.1 06 CommonSupplyforOutput09(Fromfuse4) Brown
X5.1 07 ReflexSolenoid Red
X5.1 08 NotUsed n/a
X5.1 09 NotUsed n/a
X5.1 10 CommonSupplyforOutput10(Fromfuse5) Orange
X5.1 11 BrakeSolenoid Orange
X5.1 12 NotUsed n/a
X5.1 13 NotUsed n/a
X5.1 14 CommonSupplyforOutput11(Fromfuse4) Brown
X5.1 15 ZeroDegreeSolenoid01 Grey
X5.1 16 CommonSupplyforOutput12(Fromfuse4) Brown
X5.1 17 NotUsed n/a
X5.1 18 ZeroDegreeSolenoid02 Grey
Plug Pin Function Wire Colour
X5.2 01 NotUsed n/a
X5.2 02 CommonSupplyforOutput13(Fromfuse4) Brown
X5.2 03 NinetyDegreeSolenoid01 Green
X5.2 04 NotUsed n/a
X5.2 05 NotUsed n/a
X5.2 06 CommonSupplyforOutput14(Fromfuse4) Brown
X5.2 07 NinetyDegreeSolenoid02 Green
X5.2 08 NotUsed n/a
X5.2 09 NotUsed n/a
X5.2 10 CommonSupplyforOutput15(Fromfuse4) Brown
X5.2 11 OptionalExtra(notassigned) ???
X5.2 12 NotUsed n/a
X5.2 13 NotUsed n/a
X5.2 14 CommonSupplyforOutput16(Fromfuse4) Brown
X5.2 15 CarouselSteeringSolenoid01 Grey
X5.2 16 CommonSupplyforOutput17(Fromfuse4) Red
X5.2 17 NotUsed n/a
X5.2 18 CarouselSteeringSolenoid02 Grey
