Art. 1406 is a Simplebus2 system module allowing the
forwarding of video entry phone calls to smartphones/
tablets via the Comelit SimpleApp; this application for
Android and iOS can be used to send lock-release
commands and to execute external unit self activation
for live streaming from the camera.
If other Comelit systems are installed, their functions
can be added to the Comelit app.
The module supports up to 50 apartments, with 15
apps that can be enabled for each apartment.
Receiving calls on the app is enabled if at least one
Comelit internal unit is installed inside the apartment.
Telephone calls can be forwarded if a SIP service is
available.
Fig. 1 page 4
1. Power LED
2. Connection terminals
| L | L | Simplebus2 bus line connection
| + | - | Power supply terminals 12-56 VDC.
Power supply not supplied by the bus line!
Power using art. 1595 or 1212/B.
3. CV5 Jumper Line termination, this must be
closed if art. 1406 is installed at the end of the
riser as a replacement for art. 1216 (factory
setting: closed).
4. S1 DIP-switches Microswitches for configuring
Simplebus addresses.
5. Reset DIP-switches Microswitches for carrying
out the factory reset procedure.
6. Indicator LEDs
Flashing slowly
System starting up / Updating
Steadily lit
Simplebus line present / System ready
Flashing quickly
Simplebus line missing / Short-circuited
7. CV1 (See diagrams, page 26) (Factory setting:
closed)
8. Ethernet port for non-PoE internet connection.
DHCP addressing mode
9. Indicator LEDs
Red Green Yellow
O -
No internet
connection
Cable di-
sconnected
Flashing
slowly
-
Internet conn.
present but
not connected
to the Comelit
Cloud
Ethernet
communica-
tion active
Flashing
quickly
Restore
factory
settings
Restore factory
settings
Ethernet
communica-
tion active
Steadily
lit
-
Device working
and connected
to the Comelit
Cloud
No comm.
Ethernet
Technical specifications
Power supply voltage 12 - 56 VDC
Min. absorption
0.96 W @12
VDC
Max. absorption (in audio) 3 W @12 VDC
Min. absorption 1.6 W @56 VDC
Max. absorption (in audio) 3.7 W @56 VDC
Simplebus2 bus line connection to 4888C
Absorption in standby (CV1 used) 1.8 mA
Max. absorption (in audio, CV1 used) 270 mA
Simplebus2 bus line connection to 1210A
Absorption in standby (CV1 not used) 1.8 mA
Max. absorption (in audio, CV1 not used) 76 mA
Operating temperature -5 - 50°C
Operating humidity (max. RH) 95% max.
Dimensions (4 DIN modules) (mm) 90x70x59 mm
To configure module 1406, carry out the 3
steps below:
1. Set DIP-switch S1 according to the
configuration of your system
Module 1406 stores up to 50 Simplebus addresses,
which corresponds to 50 apartments that can be
configured in your system.
} From the 3 instances outlined below, choose the
one which corresponds to your system setup and
set the DIP-switch for art. 1406 as per instructions.
INSTANCE 1
• SyStem wIth SImplebuS addreSSeS In
progressive increasing order from 1 to 50:
Apartment 1 (Index 1)  Address 1
Apartment 2 (Index 2)  Address 2
Apartment 3 (Index 3)  Address 3
…
Apartment 50 (Index 50)  Address 50

} Set S1 microswitch 1 to the ON
position.
(Factory setting)
S1
} Raise and lower (ON OFF) reset microswitch
2.
» Art. 1406 will automatically program the
Simplebus addresses of the 50 apartments,
starting from address 1.
» Art. 1406 will restart automatically.
