Comelit Mini 6701W - System Management and Addressing; Programming Reset Function

14
Changing monitor ringtones
1. Press and hold for 6 sec.
» a confirmation tone will sound
» the LED
will flash to indicate "programming" mode.
√ the procedure can only take place while the system is in standby; otherwise the LED
will flash 4 times to inform the
user that the system is busy.
2. Press and release
Once (1 confirmation tone is emitted) to change the ringtone for calls from the external unit.
Twice (2 confirmation tones emitted) to change the switchboard ringtone.
3 times (3 confirmation tones are emitted) to change the ringtone for intercom calls made from the internal unit.
4 times (4 confirmation tones are emitted) to change the floor door call ringtone.
Any further pressing of the
button repeats the sequence described above.
3. Press and release
to scroll through the various available ringtones in sequence.
4. Press
to confirm selection of the last ringtone heard and to exit (at any time) change monitor ringtone mode.
» one confirmation tone is emitted
» LED
switches o
5. Repeat steps 1 to 4 to change the other ringtones.
Take note of the S2, S1 settings and restore on completion of programming
Factory settings:
• Button functions for the S2 DIP switches 1-2-3-4 combination
• Intercom address absent
• Range function and min./max. addresses absent
• Ringtone reset
Programming reset
1. 2.
S1
S2
5 sec
