4
Description of buttons
Indicator LED description
f Press the desired button once to activate the associated function.
Wait for approximately 1 sec. before pressing the same button again. Pressing the same button several times in
quick succession will cancel the command.
LOCK-RELEASE
Use this key to open the corresponding door lock.
ACTUATOR default (programmable*)
Allows activation of the associated relay.
SELF ACTIVATION default (programmable*)
Allows activation of the external video unit, and therefore viewing of the external image.
SILENT MODE (Privacy)
The ringtone will be silenced on receipt of a call from the external unit and from the switchboard.
PROGRAMMABLE BUTTONS
Applies to monitor 6701W/8
(*) Buttons may be programmed as:
• DOOR OPENING UPON CALL (Doctor)
Allows automatic operation of the associated lock-release on receipt of a call from an external unit.
f To activate/deactivate Door opening upon call, press and hold the button programmed for this function.
• INTERCOM
Allows a call from one internal unit to one or more internal units.
• CALL TO A MAIN OR SECONDARY SWITCHBOARD
• PRIORITY CALL TO SWITCHBOARD (“PAN”)
• CALL TO CARETAKER DOOR-ENTRY PHONE
Flashing LED: incoming call
1 flash after pressing button: confirms door opening
slow flashing: door open
FLASHING LED: device in programming mode
4 flashes: system engaged
Steady LED: Silent mode (Privacy) activated
3 flashes every 5 sec.: Door opening upon call function (Doctor) active
