12
1. To enter programming mode, set S2 DIP-switch 6 to combination 1
» the Privacy LED flashes
S2 DIP
1 2 3 4 5 6
0 0 0 0 0 1
S2
Example
S2 BUTTON PROGRAMMING
DIP 1 DIP 2 DIP 3 DIP 4
1 0 1 1
INT INT
General intercom
Example programming of button 1 single-family general intercom, and button 2 general intercom to address 9, of a device
with user code 5.
(Button = INT) Set S2 DIP switches 1-2-3-4 to the combination 1 0 1 1,
set S1 with address 5 in accordance with the addressing table. Proceed with programming from point 3.
(Button = INT) Set S2 DIP switches 1-2-3-4 to the combination 1 0 1 1,
set S1 with address 9 in accordance with addressing table. Proceed with programming from point 3.
Selective intercom
Example programming of button 1 selective intercom to address 2 and button 2 selective intercom to address 3, of a
device with user code 1 and intercom address 1.
(Button = INT) Set S2 DIP switches 1-2-3-4 to the combination 1 0 1 1,
set S1 with address 2 in accordance with TABLE B .Proceed with programming from point 3.
(Button = INT) Set S2 DIP switches 1-2-3-4 to the combination1 0 1 1,
set S1 with address 3 in accordance with TABLE B. Proceed with programming from point 3.
3. Press and release the button to be associated with the function
» Correct procedure indication: the Lock release LED flashes for a few seconds and a confirmation tone sounds
» Procedure error indication: the Audio LED flashes for few seconds and an error tone sounds
4. To exit programming mode, set S2 DIP switch 6 to the combination 0
» the Privacy LED switches off
5. After programming, set S2 DIP switches 1-2-3-4 to the combination 1111. Restore the user code setting on S1 (see
addressing table.
Intercom call: button programming
2. Refer to the table Basic configuration and select a combination in which the intercom function is listed for the buttons you
wish to program.
