2. “MB 103” TEMPERATURE CONTROL UNIT TYPE
2.1 Drawing
External dimensions (Fig. 1) of the “MB 103” Temperature Control Unit:
FRONT PANEL REAR PANEL
SIDE VIEW
Fig. 1
96 mm
96 mm
107 mm9 mm 10 mm
