COMESTERO GROUP M21/03.02
Rev.02
of 25/09/03
Page 14 of 34
7.3 PC KIT
The computer kit is certainly the most complete system to adjust and check every single option of
the equipment.
It consists of a CD-ROM containing the software, an interface cable containing an SMD board for
RS232 connection, a feeder, a validator support, and a test box useful for the power supply and to
check the correct operation of the validator.
To this purpose please refer to “CLONE 5” PC kit manual.
For versions RM5 X CC a dedicated program is available.
8
8
.
.
C
C
O
O
N
N
F
F
I
I
G
G
U
U
R
R
A
A
T
T
I
I
O
O
N
N
Every validator is identified by a code consisting of six characters which determines the
configuration, i.e. the operation mode. Reference is now made to the code below which appears on
the validator label.
RM5 X nn
RM5 X nn
It identifies the type of It identifies the type of It identifies the type
Coin validator mechanical set-up of configuration
V, F,G
The currently available versions are:
RM5 X 00: Electronic validator
RM5 X CC: Validator with CC Talk protocol
RM5 X E0: SPAGNA mode validator
RM5 X AT: SPAGNA mode validator with differentiated time pulses
RM5 X B0: Binary validator
RM5 X BC: Confida binary validator
RM5 X 0M: Multipulse validator
RM5 X 10: Dual price totalizer
RM5 X 14: Single price totalizer with internal time reset
RM5 X FD: Totalizer for fountains
RM5 X 20 – RM5 X 21: Credit pulse emission totalizer (RM5 X 20); with possibility of controlling a
separator of cashed coins (RM5 X 21).
RM5 X 30: Progressive timer
RM5 X 3R: Progressive timer with on request timed credit emission
RM5 X 3C: Progressive timer with counter output
RM5 X 40: Totalizer with on request credit pulses
RM5 X 60: Totalizer with on request timed credit emission
RM5 X 70: Single price multiple sale totalizer for photocopiers
NOTE: Versions X 01 and X 21 are identical to X 00 and X 20. except that they have the
external separator control function enabled. See relevant paragraph.
