Comestero rm5 - PROGRESSIVE TIMER CONFIGURATION (RM5 X30 3 R 3 C)

COMESTERO GROUP M21/03.02
Rev.02
of 25/09/03
Page 24 of 34
- enabling the reading of the internal counter for introduced coins and reset
- adjusting pulse length between 10msec and 2 sec (standard signal 100 msec +0 – 2%)
- disabling every single coin acceptance channel
- setting credit cost and bonus levels
To facilitate the installation of this model, an RM927 interface board is provided equipped on one
side with a standard container connector for the validator and on the other side with a 5-pole
terminal board. See attached diagram.
Fig. 8
Credit – Coin Counter –Inhibition – Coin validator connector
To inhibit the electronic S.E.C.I. validator using RM 927/N interface board it is sufficient to connect
the inhibition wire of the game board to the connector shown below.
The game board is provided with an internal pull-up; therefore if you do not want to connect the
inhibition pin it is necessary to carry out the abovementioned modification.
IMPORTANT NOTE: IF THE INHIBITION PIN IS NOT USED, IT MUST BE BRIDGED TO THE
GND PIN.
If you wish to separate the coins or tokens a coin separator can be installed. To this purpose the
validator must be programmed via Clone5, to manage the separator (RM5 X 21). When the
separator function is enabled, the outputs related to channels 5 and 6 (Pin 3 and 4) are used to
control the separation coils.
PIN OUT OF RM5 X 20 VALIDATOR 10 PIN CONNECTOR
Pin No. Meaning Pin No. Meaning
1 Gnd 6 Inhibition
2 +12-24Vdc 7 Display Clock
3 Display Data 8 Coin Counter
4 Display Enable 9 Credit
5 N.U. 10 N.U.
PIN OUT OF RM5 X 21 VALIDATOR 10 PIN CONNECTOR
Pin No. Meaning Pin No. Meaning
1 Gnd 6 Inhibition
2 +12-24 Vdc 7 Display Clock
3 Coil separator B 8 Coin counter
4 Coil separator A 9 Credit
5 N.U. 10 N.U.
8
8
.
.
1
1
0
0
P
P
R
R
O
O
G
G
R
R
E
E
S
S
S
S
I
I
V
V
E
E
T
T
I
I
M
M
E
E
R
R
C
C
O
O
N
N
F
F
I
I
G
G
U
U
R
R
A
A
T
T
I
I
O
O
N
N
(
(
R
R
M
M
5
5
X
X
3
3
0
0
3
3
R
R
3
3
C
C
)
)
R
R
M
M
5
5
X
X
3
3
0
0
:
:
P
P
R
R
O
O
G
G
R
R
E
E
S
S
S
S
I
I
V
V
E
E
T
T
I
I
M
M
E
E
R
R
It recognizes 59 coins which can have even 59 different values, it sums them up and when a
previously set value is reached (basic service cost), it enables a signal for a defined time (basic
