In validator configuration with SPAGNA protocol, RM5 can manage up to six different coin values,
i.e. up to six different outputs. If the equipment has to pilot a coin separator the outputs will be only
4, as two outputs are destined to pilot the separator.
Spagna Validator means a coin validator which, after introducing a coin, before giving the standard
100 msec validation pulse ( +0 -2% ), generates a 10msec notice pulse on the output
corresponding to the programmed channel. During this time the game board must decide whether
to accept the coin and to activate the separator to convey it to the hoppers.
For this operation two inhibition pins are available on the validator, PIN 6 concerning the validator
inhibition, PIN 5 concerning the separator inhibition. The board shall keep these 2 pins high (+ 5
Vdc, inhibition status). Further to the insertion of a coin, the validator sends the notice signal to the
machine, now the machine can decide whether to accept the coin, placing PIN 6 to mass (validator
inhibition) and whether to separate it or convey it to the cash by acting on PIN 5 (separator
inhibition).
