COMESTERO GROUP M21/03.02
Rev.02
of 25/09/03
Page 34 of 34
1
1
3
3
.
.
T
T
E
E
C
C
H
H
N
N
I
I
C
C
A
A
L
L
S
S
P
P
E
E
C
C
I
I
F
F
I
I
C
C
A
A
T
T
I
I
O
O
N
N
S
S
SIZE: Standard 3 Inches and ½ ( Ref. page 17 )
WEIGHT: 185 Grams
OPERATING
TEMPERATURE: Between 0 and 55 °C from 10% yo 75% of
non condensed humidity
STORAGE
TEMPERATURE: Between 0 and 55 °C
POWER SUPPLY: 12 Vdc / 24 Vdc ± 10%
CONSUMPTION: Test carried out at 12 Vdc
Stand-by 35 mA Max
Coin measurement 50 mA Max
In acceptance 340 mA Max
OUTPUTS: Low active signal: < 1.0 Vdc. (Open collector NPN)
V max 24±10% Vdc
I max 200 m A (CH1 to CH4)
800 m A (CH5 and CH6) for separator control
CHANNEL NO.: 60,59 can be used (depending on
version)
COIN SIZE : Diameter from 16 to 31,5 mm
Thickness 3,3mm Max
CONFORMITY DECLARATIONS: EN 61000-6-3 - Emissions
EN 61000-6-1 -EMC
EN 55022 Immunity from Radio Noises
and Interferences
EN 60950 Safety
NOTE: In case of inductive load, it is necessary to externally protect outputs with clamp
diodes. See paragraph“Coin validator connections”
