5W 10W

Board Module Diagram

Limit

Wifi-

LED

Power-

LED

Card

Power supply

X MotorY1 MotorY2 Motor

Laser-

PWM

Laser-

Power

WIFI

USB Port

24V

output

STEP9.Loosen the ﬁxing screws on both sides of the laser module to focus the height of the laser

module. (5W laser module focal length is 23mm, 10W laser module focal length is 45mm)

Frame Assembly Pt.9

23mm

2mm

45mm

7mm
