Compact Scaler Switcher
Comm-Tec S.r.l. 26 www.comm-tec.it
Command
Function
Feedback Example
1360×768/ 1280×800/
1280×720/ 1024×768/1600x900
50633%
Check the image mode
Picture Mode: xx (xx= Dynamic/
Standard/ Mild/ User)
50635%
Check the image aspect ratio
Aspect Ratio: xx (xx= 16:9/ 4:3/
auto/)
50636%
Check the brightness
Brightness: xx (xx=00~99)
50637%
Check the contrast
Contrast: xx (xx=00~99)
50638%
Check the saturation
Saturation: xx (xx=00~99)
50639%
Check sharpness
Sharpness: xx (xx=00~99)
50640%
Check the color temperature
Color Temperature: xx
(xx= Cool/ Medium/ Warm/
User.)
50651%
Check Volume Icon display status
Volume Icon: xxxx
50712%
Check the audio input sources for DP
DP Audio from Embedded
50751%
Check whether the Source audio is
mute or not
Source Mute/Unmute
50752%
Check whether the MIC audio is mute
or not
MIC Mute/Unmute
50753%
Check the freeze status
Freeze: enable/disable
50754%
Check the panel locked status
Front Panel Lock/UnLock
50783%
Display statues including MIC,
Source audio, Resolution, Manual/
Auto-switching modes, VGA audio
mute on/off, DP audio status
Source Volume: XX
Mic Volume: XX
Input: XXXX
Resolution: XXXX
LINE Mute/Unmute
MIC Mute/Unmute
Switch status: XXXX
VGA Mute/Unmute
DP Mute/Unmute
