Commax CIP-700M User Manual

4
No

CONTENTS CONTENTS CONTENTS
1
2
3
4
5
6
7
•
Receiver volume control : Control the voice level coming from the outside unit.
•
volume control : Control the call sound volume from the outside.
8
9
10
11
12
13
14
MICROPHONE
RECEIVER VOLUME CONTROL
CALL VOLUME CONTROL
MENU(MENU SWITCH)
SELECT(SELECT BUTTON)
UP BUTTON
DOWN BUTTON
15
16
17
18
POWER SWITCH
PROGRAM DOWNLOAD
MASTER CONNECTION
DC POWER_INPUT
No

No

3. Part name and function
SPEAKER
POWER AND DISPLAY LED
MONITORING BUTTON
GUARD CALL BUTTON
CALL BUTTON
PRIORITY CALL/MASTER CALL
DOOR OPEN&CLOSE/WIRELE SS PHONE CALL
4 5
1.3. Wireless network connection
Press the ‘Setting’ button for setting screen.
Wi-Fi On/Off
Setting → Wi-Fi
Click the check box to turn on or off Wi-Fi.
Wi-Fi Connection
Setting → Wi-Fi setting
You can search surrounding network and connect to selected wireless network.
Select the Wi-Fi from the network list of auto-discovered and enter the password to connect network if
necessary. If protected Wi-Fi with lock, the password need to be entered to use the Wi-Fi.
Add Wi-Fi directly
When the Wi-Fi you want is not discovered, you can add it entering the Wi-Fi information directly to the
list.
Select “Add Wi-Fi network” at the bottom of Wi-Fi list.
Enter SSID of network, select security type, enter the password and select EAP way. The different
information is shown according to the security type.
Disconnect Wi-Fi
Not to connect the previous Wi-Fi automatically, initialize registered network information. First, select
connected Wi-Fi and select Don’t save. Then, the Wi-Fi will be disconnected and the previous connect
information is initialized.
※
You need to set the Ethernet IP address and the Wi-Fi IP address differently.
