Commax CVD-AF04S - Overview of DVR; Front Panel Interfaces; Rear Panel Interfaces

User Manual
2
2. Overview of DVR
2.1 Front Panel
No
Interface
Functions
1
LED
While the power supplied, the LED lights on
2
LED
When read/write HDD, the LED lights on.
3
IR Port
Receives IR signal from Remote Controller
4
USB Port
Port for connecting USB mouse or memory
2.2 Rear Panel
2.2.1 CVD-AF04S
2.2.2 CVD-AF08S
1
2
3
4
