Commax DRC-481L User Manual

- 6-
DRC-500L
No
1
2
3
4
5
6
7
8
9
Description
Speaker
Key Pad
Program Button
Electronic Key Button
Guard Button
Cancel Button
Call Button
Mic
RF/ID Receiver (Optional)
No
10
11
12
13
14
15
16
17
18
Description
Night Lamp
Display Window (FND)
CCD Camera
Computer Connection Termina
Guardhouse Interphone Termina
Household Interphone (1)
Household Interphone (2)
Video Out(Surveillance Monitor Connection)
Infrared Sensor Terminal
No
19
20
21
22
23
24
25
Description
Security Switch Connection
Power: DC15V/1A(CS-15C)
Reset Button
Selection Switches
Receiver Volume Control
Door Release Terminal
Power: AC220V/60Hz
No. 1: Computer Connection
No. 2: Electronic Key Selection
