ComNav Technology G100 User Manual

SinoGNSS G100/G200 User Guide
20
4 GIS Data Collection with G100
G100 receiver is designed for GIS application while G200 receiver is designed for RTK,
but G200 can also work in GIS application.
G100/G200 can work fluently with third-party GIS software, this section take
Collector for ArcGIS for example.
4.1 Output NMEA data
Firstly, please visit ComNav Technology website to access CRU software:
http://comnavtech.com/download.asp?bigclassid=28
 Connect receiver to PC with DB9 cable, run the CRU software.
 Click “Set Port”, select the correct COM port and Baud Rate, then click “OK”.
Usually the Baud Rate of the port is 115200.
Click “Command”, send the command “log version”.

ComNav Technology G100 Specifications

General

Brand	ComNav Technology
Model	G100
Category	Receiver
Language	English
