Appendix B AT330 Antenna Specification
Antenna
Antenna Type
Geodetic
Frequency Range
GPS: L1, L2, L5
GLONASS: L1, L2
BeiDou: B1, B2, B3
GALILEO: E1, E2, E5
Impedance
50 Ohm
Polarization
RHCP
Axial Ratio
≤3dB
Azimuth Coverage
360°
Noise Figure
≤2.0
Gain at Zenith
5.5dBi
Phase Center Accuracy
±2mm
LNA
LNA Gain
40dB
≤2dB
Noise Figure
≤2.0
VSWR Output
<0.4 m 3D RMS
Operation Voltage
3 - 18VDC
Operation Current
≤45mA
Ripple
±1dB
Group Delay
<5ns
Physical
Dimension
Φ152x62.2mm
Connector
TNC Female
Weight
374g
Environmental
Operating Temperature
-40℃ to +85℃
Storage Temperature
-55℃ to +85℃
Humidity
95% No-condensing
