CompAir D50H RS User Manual

11. Annex
53
11.1.3 Technical data EUROPE version air-cooled D75H RS-A
Maximum operating pressure
bar g
10.0
Minimum operating pressure
bar g
5.0
Ambient temperature
°C
2 … 40
at min. speed
at max. speed
5 bar
Flow
m
3
/min
1.91
11.39
8 bar
Flow
m
3
/min
1.82
11.29
10 bar
Flow
m
3
/min
1.72
10.32
Discharge temp. of air above ambient temp.
°C
20 (at max. rpm)
Sound pressure level (to Cagi Pneurop PN8NTC2)
dB(A)
76 (50Hz) / 78 (60Hz)
Electrical data
Nominal electric motor power
kW
75
Voltage (frequency)
380 - 460V (50,60Hz)
Max. total current consumption at 380V / 400V / 460V
A
148 / 141 / 123
Starting current
Max. full-load current
Motor protection type
IP-55 (IE2) - IEC 60034-2-1 ECA Qualifying
Nominal speed min./max.
rpm
750 … 3550
Nominal fan motor power
kW
2 x 2.25 (IP-54)
Recommended cable cross-section 380V / 400V / 460V
mm
2
3x50 PE25 / 3x50 PE25 / 3x35 PE16
Recommended fuse size 380V / 400V / 460V
A
160 / 160 / 125
Cooling
Cooling air flow through ventilator
m
3
/min
280
Cooling air outlet temperature above ambient temp.
°C
20
Max. allowable pressure drop in duct at ambient 35°C / 45°C
Pa
80 / 0
Weights, dimensions and fill amounts
Compressor water filling
l
75
ca. drinking water consumption in 24h (for a water change in 24h at
3.5bar water mains pressure)
l
20
Drinking water mains pressure
bar
2.5 ... 6.0
Residual water content in compressed air
g/m
3
0.1 … 0.3
Compressed air connection
R 2"
Weight
kg
1810
Dimensions L x W x H
mm
2158 x 1412 x 1971
