CompAir D50H RS User Manual

11. Annex
55
11.1.5 Technical data EUROPE version air-cooled D50H RS-A
Maximum operating pressure
bar g
10.0
Minimum operating pressure
bar g
5.0
Ambient temperature
°C
2 … 45
at min. speed
at max. speed
5 bar
Flow
m
3
/min
1.30
7.64
8 bar
Flow
m
3
/min
1.20
7.49
10 bar
Flow
m
3
/min
1.17
6.74
Discharge temp. of air above ambient temp.
°C
15 (at max. rpm)
Sound pressure level (to Cagi Pneurop PN8NTC2)
dB(A)
75 (50Hz) / 77 (60Hz)
Electrical data
Nominal electric motor power
kW
45
Voltage (frequency)
380 - 460V (50,60Hz)
Max. total current consumption at 380V / 400V / 460V
A
100 / 95 / 83
Starting current
Max. full-load current
Motor protection type
IP-55 (IE2) - IEC 60034-2-1 ECA Qualifying
Nominal speed min./max.
rpm
750 … 3700
Nominal fan motor power
kW
2 x 2.25 (IP-54)
Recommended cable cross-section 380V / 400V / 460V
mm
2
3x35 PE16 / 4G25 / 4G25
Recommended fuse size 380V / 400V / 460V
A
125 / 100 / 100
Cooling
Cooling air flow through ventilator
m
3
/min
280
Cooling air outlet temperature above ambient temp.
°C
15
Max. allowable pressure drop in duct at ambient 35°C / 45°C
Pa
90 / 40
Weights, dimensions and fill amounts
Compressor water filling
l
75
ca. drinking water consumption in 24h ( for a water change in 24h at
3.5bar water mains pressure)
l
20
Drinking water mains pressure
bar
2.5 ... 6.0
Residual water content in compressed air
g/m
3
0.1 … 0.3
Compressed air connection
R 2"
Weight
kg
1570
Dimensions L x W x H
mm
2158 x 1412 x 1971
