11. Annex
51
11 Annex
11.1 Technical data
11.1.1 Technical data EUROPE version water-cooled D110H RS-W
Maximum operating pressure
bar g
10.0
Minimum operating pressure
bar g
5.0
Ambient temperature
°C
2 … 45
at min. speed
at max. speed
5 bar
Flow
m
3
/min
3.37
18.55
8 bar
Flow
m
3
/min
3.11
18.34
12 bar
Flow
m
3
/min
3.04
16.27
Discharge temp. of air above ambient temp. (at max. rpm)
°C
16
Sound pressure level (to Cagi Pneurop PN8NTC2)
dB(A)
72/78 (at 70% load / at full load)
Electrical data
Nominal electric motor power
kW
110
Voltage (frequency)
380 - 460V (50,60Hz)
Max. total current consumption at 380V / 400V / 460V
A
223 / 212 / 184
Starting current
Max. full-load current
Motor protection type
IP-55 (IE3) - IEC 60034-2-1 ECA Qualifying
Nominal speed min./max.
rpm
750 … 3700
Nominal fan motor power
kW
1 x 0.37 (50Hz) (IP-54) ; 1 x 0.66 (60Hz) (IP-54)
Recommended cable cross-section
mm
2
3 x 95 PE 50
Recommended fuse size 380V / 400V / 460V
A
224 / 224 / 200
Cooling
Cooling air flow through ventilator
m
3
/min
115
Cooling water quantity
l/min
170
Discharged heat quantity
%
max. 10% of terminal power
Cooling water inlet temperature
°C
5 / 35
Cooling water outlet temperature
°C
45
Cooling water pressure
bar (g)
5
Pressure loss, cooling water side
bar
2.3
Cooling water connection
R 1 1/4" / R 1 1/4"
Weights, dimensions and fill amounts
Compressor water filling
l
91
ca. drinking water consumption in 24h ( for a water change in 24h at
3.5bar water mains pressure)
l
20
Drinking water mains pressure
bar
2.5 ... 6.0
Residual water content in compressed air
g/m
3
0.1 … 0.3
Compressed air connection
R 3"
Weight
kg
2200
Dimensions L x W x H
mm
2158 x 1412 x 1971
