CompAir Mako CMM - Page 41

100
1 6
8
7
131416 12 1111 10
2 3 4 5
1511
Item No View Description Part No. Qty.
1 ---- 0 PPM Cylinder 009006-7800 1
2 CMM Overlay, with Membra ne 003CMM08319 1
3 ----- CMM Door, Wall Mount 008PUR09011 1
20 0 Internal Vi e w of Encl osure
4 ----- Door Latch- Tool Opera ted - Small 003E35675 1
5 ----- CMM Wa ll Mount Hous ing - Welded 008PUR09013 1
6 ----- 20 PPM Cylinder 003M48841 1
7 ---- Cla mp, Tes t Cylinder 003P1120 2
8 ----- Regulator, Sample Ga s Flow 003E410 2
Item No View Description Part No. Qty.
10 300 Inlet Ma nifold As s embly
11 ----- Strain Reliew -Bulkhea d EL016 3
12 400 Moisture Sensor Ass embly Cable
13 ----- Swi tch -On/Off - Green LED 003E0246 1
14 ----- Power Cord 003M484 1
15 ----- Compres sor Ha rness 1
16 ----- Hinge -In-Line Lift Off 003961050050 2
