Compak E5 - Adjustment Procedures; Grinder Setup and Portafilter Support

12
K09657H02 | PROC-CAL/002/03 USER MANUAL | V. 11/07/2023
. ADJUSTMENT
Remove the hopper lid ( ), fill the hopper
with coee ( ), and replace the lid on the
hopper ( ) (Fig. 3).
Fig. 3
Plug in the grinder, and press the main power
switch ( ) to ON position, and open the
bean trap ( ) to allow coee to pass into the
grind chamber (Fig. 4).
Fig. 4
.. GRINDER SET UP
Place the hopper ( ) on the grind regulator
( ) and make sure the bean trap ( ) is in
the closed position (Fig. 1).
Fig. 1
Lock the hopper ( ) in place using a Phillips
head screw driver to gently tighten the
hopper security screw making it match to the
hole at the bean hopper collar ( ) (Fig. 2).
Fig. 2
