Compak E5 - Maintenance and Component Replacement; General Warnings and Grind Chamber Maintenance

27
K09657H02 | PROC-CAL/002/03 USER MANUAL | V. 11/07/2023
Not following the recommended
burr life guidelines can
compromise the safety of the
grinder.
These operation should be done
by a qualified service technician
wearing safety gloves.
.. GENERAL WARNING
Before performing any type of maintenance,
you should:
• Always turn OFF the main power switch
to the o position ( ).
• If the grinder is jammed, unplug it
from the power source and contact an
authorized service technician.
In case of breakdown or malfunction, turn o
the appliance, we should never try to repair
it, it is essential to call the nearest technical
service.
NOTE: Not following these
warnings can compromise the
safety of the grinder as well as the
user.
.. GENERAL MAINTENANCE OF
THE GRIND CHAMBER
To guarantee the eiciency and correct
operation of the grinder, it is essential to follow
manufacturer instructions and ensure that all
maintenance work is carried out by qualified
sta.
Dull burrs will result in; a lower quality grind,
greater heat generation in the coee and grinder,
increased electrical consumption, and finally it
puts additional stress on the grinder motor.
. MAINTENANCE
.. GRINDING GROUP MAINTENANCE
To perform grind chamber maintenance
please observe the following steps:
12.3.1. Turn o the grinder by making sure
the main power switch ( ) is on the OFF
position. Disconnect the plug from the power
source. Loosen the hopper security screw
( ) using a Phillips head screw driver as
seen in (Fig. 1).
Fig. 1
12.3.2. Check that the shutter is in the closed
position before removing the hopper from
the grind regulator ( ) (Fig. 2).
Fig. 2
