Compak E5 - Operating the Grinder; Main Switch, Usage Modes, and Push Operation

14
K09657H02 | PROC-CAL/002/03 USER MANUAL | V. 11/07/2023
. ADJUSTMENT
.. MAIN SWITCH
The main switch ( ) has the following
positions: AUTOMATIC / OFF / MANUAL
or ON /OFF.
E5
E6-E8
E10
The equipment’s
electronic functions
are activated
I ON
Equipment o
O OFF
Equipment in manual
mode.
II
.. USAGE
Through the program menu (section 10.4.3),
it is possible to select three distinct functional
modes: PUSH, DETECTION and TOUCH.
.. PUSH MODE
In the PUSH mode, a pre-programmed single,
double or triple dose can be set by simple
pressing the corresponding icon on the TFT
screen ( ).
The preselection of a single, double or triple
dose will remain active until it is changed by
pressing one of the three numbered icons. This
preselection is reflec ted on the TFT screen
( ) with the icon of the active selection in the
secondary color, and the rest of the icons in the
main color.
Dispensing the preselected dose by pressing
the lower pulse button ( ) one time. When the
grinding cycle begins, a timer countdown will
begin on the TFT screen ( ), which will count
down the timed dose cycle to zero.
. OPERATION
NOTE: If the coee
throughput is very low, this
is because the coee is
being ground very fine. If
the throughput is very high,
this is because the coee is
being ground very coarse. A
perfect Espresso is produced
when the grinding gives an
infusion of 25 ml of coee in
25 seconds using about 7 g of
ground coee.
NOTE: It is recommended
that this operation be
performed, when changing
to a finer grinding, with the
motor running, to prevent
coee from building up
between the burrs and
blocking the grinder.
.. PREPARATION OF THE
PORTAFILTER DETECTOR OPTIONAL
1. Place the detector on the double portafilter
(Fig. 1).
2. Check that the detector ring tab is properly
closed (Fig. 2).
3. Make sure that the arrow is in the correct
position on the lower side (Fig. 3).
Fig. 1 Fig. 2 Fig. 3
