Hardware Reference Guide
4–1
4
Using the Legacy Module
The optional Legac
y Module provides connectors for parallel
1
and
serial
2
de
vices, PS/2 keyboard
3
, and PS/2 mouse
4
.
sp-hrg.book Page 1 Thursday, December 13, 2001 9:14 AM
22
24
