4–4 Hardware Reference Guide
Using the Legacy Module
Removing the Legacy Module
1. Exit all software applications, shut down the operating system
software, turn off the personal computer and any external devices,
then disconnect the power cord from the power outlet.
2. Remove the access panel. Refer to “Removing and Replacing the
Access Panel” on page 3-1.
3. Remove the grounding screw. Be sure to keep it in a safe place.
4. Press out on the plastic tabs that secure the Legacy Module to the
personal computer, then push them through the holes in the rear
panel to remove the cover.
Removing the Legacy Module
5. Replace the rear panel cover and the grounding screw.
6. Replace the access panel.
sp-hrg.book Page 4 Thursday, December 13, 2001 9:14 AM
