Removal and Replacement Procedures
Maintenance and Service Guide 5–19
1. Prepare the notebook for disassembly (Section 5.3).
2. Turn the notebook bottom side up with the front facing you.
3. Remove the TM2.5 × 7.0 screw that secures the keyboard to
the base enclosure (Figure 5-10).
Figure 5-10. Removing the Keyboard Screw
4. Turn the notebook top side up with the front facing you.
5. Open the notebook.
279362-003.book Page 19 Monday, May 19, 2003 1:28 PM
