5–42 Maintenance and Service Guide
Removal and Replacement Procedures
5.14 Fan
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
a. RTC battery (Section 5.6)
b. Keyboard (Section 5.7)
c. Memory expansion compartment cover (Section 5.8)
d. TouchPad (Section 5.9)
e. Switch cover (Section 5.10)
f. Display (Section 5.11)
g. Top cover (Section 5.12)
h. System board (Section 5.13)
2. Turn the system board bottom side up with the rear panel
facing you.
Fan
Spare Part Number Information
For use with Evo Notebook N620c, N610c, and N610v
models only
For use with Evo Notebook N600c models only
291266-001
255528-001
279362-003.book Page 42 Monday, May 19, 2003 1:28 PM
