1–32 Maintenance and Service Guide
Product Description
1.5 Notebook External Components
The external components on the front and right side of the
Evo Notebook N620c, N610c, N610v, and N600c are shown in
Figure 1-2 and described in Table 1-5.
.
Figure 1-2. Front and Right Side Components
Table 1-5
Front and Right Side Panel Components
Item Component Function
1 Power light On: Power is turned on.
Blinking: Notebook is in Standby. The power
light also blinks if a battery pack that is the
only available power source reaches a
low-battery condition.
2 Battery light On: A battery pack is charging.
Blinking: A battery pack that is the only
available power source has reached a
low-battery condition.
279362-003.book Page 32 Monday, May 19, 2003 1:28 PM
