Compaq Evo N600c - Removing and Replacing the Heat Sink

5–46 Maintenance and Service Guide
Removal and Replacement Procedures
5.15 Heat Sink
✎
This section applies only to Evo Notebook N620c, N610c, and
N610v models.
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
a. RTC battery (Section 5.6)
b. Keyboard (Section 5.7)
c. Memory expansion compartment cover (Section 5.8)
d. TouchPad (Section 5.9)
e. Switch cover (Section 5.10)
f. Display (Section 5.11)
g. Top cover (Section 5.12)
h. System board (Section 5.13)
Heat Sink
Spare Part Number Information
Heat sink 303103-001
