Removal and Replacement Procedures
Maintenance and Service Guide 5–47
2. Turn the system board bottom side up with the rear panel
facing you.
3. Disconnect the fan cable from the system board
(Figure 5-31).
Figure 5-31. Disconnecting the Fan Cable
279362-003.book Page 47 Monday, May 19, 2003 1:28 PM
