5ā54 Maintenance and Service Guide
Removal and Replacement Procedures
5.18 Modem Cable
ā
The modem cable is spared with the base enclosure. Modem
cables are also included in the Miscellaneous Plastics Kit
(spare part number 241439-001).
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
a. RTC battery (Section 5.6)
b. Keyboard (Section 5.7)
c. Memory expansion compartment cover (Section 5.8)
d. TouchPad (Section 5.9)
e. Switch cover (Section 5.10)
f. Display (Section 5.11)
g. Top cover (Section 5.12)
h. System board (Section 5.13)
2. Position the base enclosure with the rear panel facing
forward.
279362-003.book Page 54 Monday, May 19, 2003 1:28 PM
