Removal and Replacement Procedures
Maintenance and Service Guide 5–55
3. Lift the modem connector out of the base enclosure 1 and
disengage the modem cable 2 from the alignment clips and
tabs in the base enclosure (Figure 5-36).
Figure 5-36. Removing the Modem Cable
4. Remove the modem cable.
279362-003.book Page 55 Monday, May 19, 2003 1:28 PM
