Removal and Replacement Procedures
Maintenance and Service Guide 5–29
5.11 Display
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.7).
3. Remove the switch cover (Section 5.10).
4. Position the display so that it is vertical.
Display
Spare Part Number Information
For use with Evo Notebook N620c models only:
14.1-inch, SXGA+, CTFT 319733-001
For use with Evo Notebook N610c and N610v models only:
14.1-inch, SXGA+, CTFT
14.1-inch, XGA, CTFT
291261-001
291262-001
For use with Evo Notebook N600c models only:
14.1-inch, SXGA+, CTFT
14.1-inch, XGA, CTFT
241433-001
241434-001
279362-003.book Page 29 Monday, May 19, 2003 1:28 PM
