5–52 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 DC-DC Converter Board
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
a. RTC battery (Section 5.6)
b. Keyboard (Section 5.7)
c. Memory expansion compartment cover (Section 5.8)
d. TouchPad (Section 5.9)
e. Switch cover (Section 5.10)
f. Display (Section 5.11)
g. Top cover (Section 5.12)
h. System board (Section 5.13)
2. Turn the system board bottom side up with the rear panel
facing you.
DC-DC Converter Board
Spare Part Number Information
For use with Evo Notebook N620c models only
For use with Evo Notebook N610c and N610v models only
For use with Evo Notebook N600c models only
319635-001
291263-001
241435-001
279362-003.book Page 52 Monday, May 19, 2003 1:28 PM
