Removal and Replacement Procedures
Maintenance and Service Guide 5ā35
5.13 System Board
ā
Make sure the PC Card eject buttons are fully depressed and there
are no PC Card devices or space savers inserted into the PC Card
slots before removing the system board.
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
a. RTC battery (Section 5.6)
b. Keyboard (Section 5.7)
c. Memory expansion compartment cover (Section 5.8)
d. TouchPad (Section 5.9)
e. Switch cover (Section 5.10)
f. Display (Section 5.11)
g. Top cover (Section 5.12)
2. Position the notebook so the rear panel faces you.
System Board
Spare Part Number Information
For use with Evo Notebook N620c models only
For use with Evo Notebook N610c and N610v models only
For use with Evo Notebook N600c models only:
Mobile Intel Pentium III processor 1.066 GHz-M
Mobile Intel Pentium III processor 866 MHz-M
319778-001
291581-001
241430-001
241432-001
279362-003.book Page 35 Monday, May 19, 2003 1:28 PM
