5–30 Maintenance and Service Guide
Removal and Replacement Procedures
5. Remove the TM2.5 × 7.0 screw that secures the display
ground cable to the top cover 1 (Figure 5-18).
6. Disconnect the display video 2 and inverter cables 3 from
the system board.
Figure 5-18. Disconnecting the Display Cables
7. Partially close the notebook.
8. Position the notebook so the rear panel faces you.
