C–2 Maintenance and Service Guide
Screw Listing
Figure C-1. PM2.5 × 2.5 Screw Location
Table C-1
Phillips Metric 2.5 × 2.5 Screw
Color Qty Length Thread
Head
Width
Black 1 4.0 mm 2.5 mm 5.0 mm
Where used:
One screw that secures the hard drive to the base enclosure
(documented in Section 5.3)
mm
279362-003.book Page 2 Monday, May 19, 2003 1:28 PM
