Screw Listing
Maintenance and Service Guide C–5
Figure C-4. PM2.5 × 5.0 Screw Location
Table C-3
Phillips Metric 2.5 × 5.0 Screw
(Continued)
Color Qty Length Thread
Head
Width
Black 3 5.0 mm 2.5 mm 4.5 mm
Where used:
Evo Notebook N620c, N610c, and N610v models—One screw that secures
the fan to the heat sink (documented in Section 5.14)
mm
279362-003.book Page 5 Monday, May 19, 2003 1:28 PM
