Compaq Evo N600c

1–40 Maintenance and Service Guide
Product Description
The Evo Notebook N600c bottom components are shown in
Figure 1-6 and described in Table 1-9.
Figure 1-6. Bottom Components—Evo Notebook N600c
Table 1-9
Bottom Components
Item Component Function
1 Media Bay Accepts a diskette drive, optical drive, or
secondary battery pack.
2 Media Bay release latch Releases the Media Bay device from the
connector.
