Compaq Evo N600c

1–42 Maintenance and Service Guide
Product Description
The components on the top of the Evo Notebook N620c, N610c,
N610v, and N600c are shown in Figure 1-7 and described in
Table 1-10.
Figure 1-7. Top Components
Table 1-10
Top Components
Item Component Function
1 Num lock light On: Num lock is on and the embedded
numeric keypad is enabled.
2 Scroll lock light On: Scroll is on.
3 Caps lock light On: Caps lock is on.
279362-003.book Page 42 Monday, May 19, 2003 1:28 PM
