Removal and Replacement Procedures
Maintenance and Service Guide 5–67
5.20 Fan Assembly
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.11)
f. Display assembly (Section 5.12)
g. Base enclosure (Section 5.13)
h. System board (Section 5.15)
i. Heat sink (Section 5.18)
Fan Assembly Spare Part Number Information
Fan assembly 407808-001
