Maintenance and Service Guide C–1
C
Screw Listing
This appendix provides specification and reference information
for the screws and screw locks used in the computer. All screws
listed in this appendix are available in the Computer Screw Kit,
spare part number 407783-001, and the Display Screw Kit, spare
part number 407795-001.
Phillips PM3.0×4.0 Screw Locations
Table C-1
Phillips PM3.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 4 4.0 mm 3.0 mm 5.0 mm
Where used:
4 screws that secure the hard drive frame to the hard drive (documented in
Section 5.4)
mm
