MNC-0500-026 24 of 32 Revision G
Amplifier Communication and Protocol, Rabbit CPU
GoTo Power (dBW)
Command Byte: ‘D’
Function: The HPA seeks the specified power level for 10 seconds.
Parameter: The desired power level in “XX.X” dBW.
Compatibility: Attenuator required.
GoTo Power (Watts)
Command Byte: ‘E’
Function: The HPA seeks the specified power level for 10 seconds.
Parameter: The desired power level in “XXXX” Watts.
Compatibility: Attenuator required.
Optional Parameter: “M” - desired power in dBm.
Example: EMxx.x
Heater Standby
Command Byte: ‘:’
Function: Enables/Disables Heater Standby mode.
Parameters:
‘0’ - Disable Heater Standby.
‘1’ - Enable Heater Standby.
High RF Trip
Command Byte: ‘M’
Function: Sets a High RF trip point. If output power exceeds the set point, an
alarm or fault is generated provided the HPA has processed an “Enable RF
Limits” command (R’).
Parameter:
“AXXXX” to set an Alarm trip point,
“FXXXX” to set a Fault trip point, “D” to disable. XXXX is the desired trip point
in Watts.
Optional Parameter: “M” - desired power in dBm.
Example: MAMxx.x
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
