Appendix A
(cont.)
THIS DOCUMENT IS THE PROPERTY OF XICOM TECHNOLOGY. REPRODUCTION OR RELEASE WITHOUT EXPRESS PERMISSION IS STRICTLY PROHIBITED.
XTD-750K, 12.75 - 14.5, L01
Document No. 305-0391-032 REV 4 Page 9 of 10
S
pec
Paragraph
No
Test Description
Test Condition
Requirements
Units
Measured
Performance
Pass
or
Fail
Min
Max
3.1.14.1
3.1.14.2
3.1.14.3
Spurious Signals
Note 1.
-37 dBc max
10 Hz to 10 kHz
(-20(1.5 + log(f)) +13) dBc max
10kHz to 500 kHz
-72 dBc max
>500 kHz
–50 dBc max
line related individual
-47 dBc max
sum of all
STD
Freq = 13.625 GHz
V
in
= 180 VAC
P
o
= P
rated
– 3 dB
Span = 2 KHz
N/A
Note 1
dBc
See attached
plot
Pass
Fail
Span = 20 KHz
N/A
Note 1
dBc
See attached
plot
Pass
Fail
Span = 200 KHz
N/A
Note 1
dBc
See attached
plot
Pass
Fail
Span = 2 MHz
N/A
Note 1
dBc
See attached
plot
Pass
Fail
Span = 20 MHz
N/A
Note 1
dBc
See attached
plot
Pass
Fail
Span = 200 MHz N/A
Note 1
dBc
See attached
plot
Pass
Fail
3.1.16
Prime Power
Power Factor
260 VAC, 60 Hz
P
o
= P
rated
Freq = 13.625 GHz
N/A 2450 VA
Pass
Fail
0.95 N/A -
Pass
Fail
180 VAC, 60 Hz
P
o
= P
rated
Freq = 13.625 GHz
N/A 2450 VA
Pass
Fail
0.95 N/A -
Pass
Fail
N/A
Sample Port Calibration
12.75 GHz
N/A
N/A
dB
13.10 GHz
N/A
N/A
dB
13.45 GHz
N/A
N/A
dB
13.80 GHz
N/A
N/A
dB
14.15 GHz
N/A
N/A
dB
14.50 GHz N/A N/A dB
Tested by: ___________________ Date: ____________ Data verified by: _______________
