Hardware Specifications
Hardware Specifications
The following table lists hardware specifications for the RTS. See Power Supply
Specifications above for detailed power supply specification information.
Topic Specification
Current consumption:
RTS 1 models
RTS 4
RTS 8
RTS 16 with external power supply
RTS 16RM with internal power supply
RTS 32RM
420 mA @ 5VDC
200 mA @ 24VDC
290 mA @ 24VDC
490 mA @ 24VDC
130 mA @ 110VAC
200 mA @ 110VAC
Power consumption:
RTS 1 models
RTS 4
RTS 8
RTS 16 with external power supply
RTS 16RM with internal power supply
RTS 32RM
2.1 W
4.8 W
6.96 W
11.76 W
14.3 W
22.0 W
Processor type ARM7
Memory 8MB SDRAM/4MB flash
Real time clock (RTS 4/8/16 with external
power supply, only)
Battery backup, 256B RAM,
watchdog time/power off monitor
Baud rate/port (maximum) 230.4 Kbps
Ethernet host interface
(Downstream port available with some
models)
10/100Base-T
(10/100 Mbps - RJ45)
Serial interface RS-232, RS-422, and RS-485
Serial connector types:
RTS 1
RTS 1 Embedded System
4/8-Port models
16/32-Port models
DB9
Header, IDC10
DB9 and DB9 to RJ45 adapter
RJ45
Network default values:
IP address
Subnet mask
Gateway
192.168.250.250
255.255.0.0
192.168.250.1
Network protocols
TCP, UDP, BOOTP, TFTP, ICMP,
ARP, SNMP (MIB-II), Telnet,
HTTP
NS-Link control:
Data bits
Parity
Stop bits
7 or 8
Odd, Even, None
1 or 2
SNMP support Monitoring only.
